Node.js in production: runtime log snooping

This post also appeared on the Joyeur blog.

This post is the one of several about how we operate Node.js in production at Joyent. Most of my experience comes from working on our Manta Storage Service, which currently comprises a few thousand Node processes across three datacenters.

Logging is one of the most primitive but most valuable forms of postmortem debugging. Logs let you figure out why a program crashed (or did the wrong thing) after it’s already done so. In this post I’ll describe a critical feature of the Bunyan logging library that we use daily to help debug failures in production: runtime log snooping.

The problem

In many production systems, there’s a nasty tradeoff: the more verbose your logs, the more information you have to debug issues, but the greater the overhead of constructing, recording, transmitting, storing, and analyzing these logs as well. Log frameworks typically manage this with log levels: you use “debug” in development, which spews all kinds of information about what the program is doing, but you use “info” or some higher level in production, which filters only the “important” messages.

But it’s often in production that you really need the debug messages that are too expensive to emit in production. It’s when you’ve been paged in the middle of the night because some service’s error count has exceeded some threshold. If you’re lucky, the failure is simple enough that the program can tell you exactly what’s happened, but more often, particularly in distributed systems, where failure modes aren’t so crisp, the error will be somewhat vague. You’ll need more information about what the program was doing in order to figure out what went wrong.

In many of these cases, restarting the service will bring it back to life, but it will also eliminate any hope of root causing the problem. You can already see yourself getting paged again a few nights later for the same issue…

Bunyan

Trent Mick at Joyent wrote a Node module called Bunyan that we use in all of our services to log everything from free-form text intended for humans to programmatically consumable events that trip alarms or feed into our billing system. Bunyan logs are just newline-separated JSON records. A few fields have special meaning, like “time” and “msg”, but programs can log whatever other JSON structures they want for interpretation by humans or other programs. (In Manta, we use Bunyan log records for billing. These log entries include structured payloads that describe the billable operation, the user, the result, and so on.¹) The “bunyan” command-line tool facilitates easy filtering, colorizing output, and so on, while programmatic consumers can parse each line as a JSON object.

There are lots of logging libraries out there, but Bunyan’s killer feature is the ability to snoop debug-level logs in production, without restarting (or otherwise impacting) the service. When an application calls log.debug("something went wrong"), and the log level is “info” (i.e., higher than “debug”), the bunyan library drops the message, as you’d expect. When you want to get at these debug messages, you fire up “bunyan -p *”, which is just sugar for:

$ dtrace -Z -x strsize=4k -x switchrate=10hz \
    -q -n 'bunyan*:::log-*{ printf("%s\n", copyinstr(arg0)); }' | bunyan

When you run this, you’re enabling DTrace probes built into Bunyan. Enabling these probes actually modifies your Node program’s behavior to fire the probe just before dropping the log message. Firing the probe traps into the kernel, where the log message is buffered and eventually funneled up to the “dtrace” process and printed out to your terminal.

This is a subtle point, but it’s very important: enabling these probes doesn’t cause the debug messages to appear in the regular log, but rather it causes these messages to be collected, buffered by the kernel, and then made available to your “dtrace” process. That means your service is still running at near full speed, not going through the code paths that write entries to the log. Importantly, if the volume of messages gets too high, DTrace will drop them rather than slow down the process. (You can tune the “switchrate” and buffer sizes to control that.)

When you don’t need the extra logging any more, CTRL-C the “bunyan” (or “dtrace”) process. The program modifications are undone, and your program goes on dropping debug log entries.

Voilá! By using Bunyan as a logging library, you get the ability to walk up to a production service and enable debug logging without restarting it. This has proven critical for a number of cases where it’s too expensive to log debug messages all the time, but we had a live service behaving badly, and restarting the service would likely have cleared the issue without giving us a chance to root-cause it.

Try it yourself

I ran these examples on OS X because it’s convenient, but all of our production services run on SmartOS (an illumos distribution). This facility works on any system that supports DTrace USDT.

If you’ve got Node installed already, it’s ridiculously easy to try this out. First, create a temporary directory and install bunyan locally:

dap@sharptooth $ npm install bunyan

then start a Node REPL, load up bunyan, and create a logger at level “info”:

    dap@sharptooth $ node
    > var r = require('bunyan')
    undefined
    > var l = new r({ 'name': 'test', 'level': 'info' })
    undefined

At this point, you can log “info” messages, but “debug” messages will be hidden:

> l.info('test info message')
{"name":"test","hostname":"sharptooth.local","pid":1076,"level":30,"msg":"test info message","time":"2013-09-27T18:13:00.820Z","v":0}
undefined
> l.debug('something went wrong')
undefined

Now in another shell, use “bunyan -p”:

# In another shell:
dap@sharptooth $ sudo bunyan -p '*'   # sudo required for DTrace

That will block waiting for something to happen. Back in the first shell, log that debug message again:

> l.debug('something went wrong')
undefined

and over in the second shell, you should see something like this:

[2013-09-27T18:16:19.679Z] DEBUG: test/1076 on sharptooth.local: something went wrong

Success! Because we used bunyan -p '*', we’ll see log messages from all Node processes on the system. You can also specify a specific pid instead of ‘*’ to see only messages from that process.

Dynamic probes for your application

Bunyan’s dynamic probes are implemented using Chris Andrews’s node-dtrace-provider module, which makes it very easy to add custom probes to any application. (The whole Bunyan integration with DTrace is about 20 lines of code.)

Another great example that we also use heavily is node-restify, which creates DTrace probes for the beginning and end of each HTTP request, as well as each of the phases of request processing (auth, parsing, logging, and so on). You can enable these probes in production to get a fine-grained look at request latency, including what parts of each request are taking a long time.

In this post, I described Bunyan, the Node.js logging library we use at Joyent. I explained how we use DTrace probes built into Bunyan to extract more debug information from a production service than we can normally extract without disrupting the service itself. We focus on tools for production because the hardest issues often show up only in production deployments, and the production environment is far more constrained than development. By building tools designed for production use, we’re able to debug failures both in the field and in development, in many cases root-causing them the first time we see them.
